Aircraft Profiles for Radio

Profiles are user-moddable through the MobiFlight software

Collaborate and share your profiles on the Discord server

Profiles marked MSFS are compatible with both FS2020 and FS2024, where applicable

Function varies by aircraft and developer

Prepar3d / FSX - PMDG 737 NGX & NGXu

Prepar3d P3D PMDG 737 NGX / NGXu

Discuss this Profile on Discord

See You Have Control for info on modding aircraft profiles.

Changelog

2026-05-21 - v1

  • Initial Release

Important

FSUIPC is required to communicate with the PMDG 737 NGX / NGXu.

You must also enable Data Broadcast from the aircraft.

Note: If you've just installed the PMDG 737 NGX / NGXu, ensure you have loaded into the aircraft at least once, and pushed a button on the FMC. This is a required step before enabling Data Broadcast.

FSUIPC

Get it here.

Choose the relevant version for your simulator.

Registration/Purchase is not required.

Enabling Data Broadcast

Locate your 737_Options.ini file.

It should be found inside your FSX / P3D installation folder, inside the folder PMDG\PMDG 737 NGX.

Add the following to the end of the 737_Options.ini file

[SDK]
EnableDataBroadcast=1

Pilot Notes

DME Mode and Brightness controls are included.

ADF Standby is not available - ADF is manipulated directly (PMDG limitation)

PMDG 737 does not have a visual indication for IDENT - the IDENT button functions but will not iluminate.

PMDG 737 does not feature ADF 2.

Download Here
