MSFS - PMDG 737

---

Important

ADF Display - Install FSUIPC7

PMDG's ADF display relies on some legacy code. FSUIPC7 must be installed for the ADF display to work properly.

FSUIPC7 - get it here. Registration/Purchase is not required.

ADF Display - Enable Data Broadcast

Note: If you've just installed the PMDG 737, ensure you have loaded into the variant (737-700, 737-800, etc.) at least once, and pushed a button on the FMC. This is a required step before enabling Data Broadcast.

Locate your 737_Options.ini file:

FS2020 Microsoft Store / Xbox App users

C:\Users\{USERNAME}\AppData\Local\Packages\Microsoft.FlightSimulator_8wekyb3d8bbwe\LocalState\packages\pmdg-aircraft-{AIRFRAME}\work

FS2020 Steam users

C:\Users\{USERNAME}\AppData\Roaming\Microsoft Flight Simulator\Packages\pmdg-aircraft-{AIRFRAME}\work

FS2024 Microsoft Store / Xbox App users

C:\Users\{USERNAME}\AppData\Local\Packages\Microsoft.Limitless_8wekyb3d8bbwe\LocalState\WASM\MSFS2024\pmdg-aircraft-{AIRFRAME}\work\

FS2024 Steam users

C:\Users\{USERNAME}\AppData\Roaming\Microsoft Flight Simulator 2024\WASM\MSFS2024\pmdg-aircraft-{AIRFRAME}\work\

Add the following to the end of the 737_Options.ini file:

[SDK]
EnableDataBroadcast=1

Do this for each {AIRFRAME} folder if you have more than one variant (e.g. 737-700 and 737-800).

Disable MMR Radios

FS2020 USERS: Select the Classic Nav Radio Panels option from the FMC (Menu -> PMDG Setup -> Aircraft -> Equipment Page 17).

FS2024 USERS: As above, but the menu item is called NAV RADIO (GABLES) and you should select the option G7500 (VHF).

This option is saved per-livery. Once it's done, you can set this airframe as a "Fixed Config" so you'll always be flying with Classic Radio Panels enabled.

---

Download Here

Discuss this Profile on Discord

See You Have Control for info on modding aircraft profiles.

---

Changelog

2026-09-18 - v6

• System 1 is selected automatically when MobiFlight is run
• General quality pass
• Updated XPDR D fast knob binding
• Updated COM 2 Whole binding

2024-09-20 - v5

• Removed a duplicate XPDR IDENT LED entry which was causing the IDENT LED to flicker

---

Optional Extras

Important notice - These files are optional and intended for advanced or additional use only after your Circuit Avionics hardware is fully set up and functioning correctly. These files are unrelated to the core functionality of your Circuit Avionics hardware and may lead to confusion or unintended results if used prematurely.

We recommend completing the setup and ensuring everything works as expected before exploring these files.

Honeycomb Bravo LED Profile for PMDG 737

For pilots who use the Honeycomb Bravo controls, we have created a MobiFlight profile which lights up the annunciator LEDs.

Download the Honeycomb Bravo LED Profile for MobiFlight here

Instructions are given in the download ZIP. A MobiFlight profile is included in the download for Sidekick users.
